3150TIN Barcode Printer
Model: 3150TIN
Description: label printer thermal, tag printer, barcode printer thermal, printer barcode label
Key parameter: 3 inch width (80mm)
USB+Serial+Etherenet
3~6inch/sec
Features:
3150TIN Barcode Printer is designed for real-time and batch label printing, which I applicable in the field of transportation, logistics, post, retail sale, and etc. The printer can be connected with other equipment with various interface cards, such as Serial, USB and LAN. It supports different paper media, including thermal paper roll, thermal label roll and sticker paper.
The printer 3150TIN Barcode Printer provides direct thermal printing at selectable speed of 2.0, 3.0, 4.0, 5.0 and 6.0 inches per second. It accepts roll feed, die-cut and fan-fold labels. All common barcode format and QR code are available. Font and bar codes can printed 4 directions and 1 to 10 times enlargement size. High performance and efficiency of label printing save your time.
●6 inch/s high-speed printing
●Support thermal paper roll, thermal label paper and sticker paper
●3150TIN Barcode Printer supports two-dimensional barcode printing function (QR CODE)
●Multiple interfaces for different connectivity: USB+Serial+Ethernet
●100MB Ethernet for faster connection to avoid label losing
●Compatible with various label softwares
●Automatic positioning of label paper
●Support BMP/PCX/BAS files download and memory
●Support English, Chinese and Korean languages etc.
●Modular designs will satisfy different Customers' demand
●3150TIN Barcode Printer supports Thermal paper, Thermal label, Adhesive thermal paper etc.
●Automatic paper calibration and adaptive temperature control function
●Innovative design with low-noise; stable and durable performance
●Support to print different density bitmap and download graphics
Specification
|
Printer |
Print Method |
Direct thermal line |
|
Resolution |
203 dpi |
|
|
Print Width |
Max. 76mm |
|
|
Print Speed |
3 ~ 6inch/s |
|
|
Interface |
USB+Serial+Ethernet |
|
|
Print head temperature detect |
Thermal sensitive resistance |
|
|
Print Head Position detect |
Micro switch |
|
|
Paper sensor |
Photoelectric sensor |
|
|
Memory |
DRAM: 8M FLASH: 4M |
|
|
Command set |
TSPL emulation |
|
|
Label |
Paper Type |
Thermal paper, Thermal label, Adhesive thermal paper, sticker paper etc |
|
Media Width |
24 ~ 82mm |
|
|
Media Diameter |
25 ~ 85mm |
|
|
Paper Off Type |
Tear off or peel-off |
|
|
Bar Code |
Enlargement & Rotation |
1 ~10 times enlargement in both directions; 0°, 90°, 180°, 270° rotation |
|
Character Size |
Font 0 ~ Font 8 |
|
|
1D Barcode |
Code39, Code93, Code128 subsets A, B, C, Codabar, Interleaved 2 of 5, EAN-13, EAN-14, EAN-128, UPC-A, UPC-E, EAN and UPC 2(5) digits add-on, MSI, PLESSEY, POSTNET, china POS, ITF14 |
|
|
2D Barcode |
QR code |
|
|
Graphics Processing |
Support BMP/PCX/BAS files |
|
|
Editing Software |
BarTender |
|
|
Operating |
Cash drawer Out |
24VDC/2A |
|
Power Supply |
AC 110V/220V, 50 ~ 60Hz, DC 24V/2A |
|
|
Work Environment |
Temperature: 5~45℃(41~104℉), Humidity: 25~85%RH |
|
|
Storage Environment |
Temperature: -10~50℃(-10~140℉), Humidity: 10%~90%RH |
|
|
Physical |
Weight |
1.65kg |
|
Dimension |
156*230*147mm |
Product Show:
Packing
|
Product Model |
Weight (kg) |
Packing |
C.G.W (kgs) |
Carton Size (cm) |
| 3150TIN Barcode Printer |
2.5 |
6 pcs/carton |
16 |
68*29*50 |
Application:
3150TIN Barcode Printer is widely used in all kinds of retail POS systems (Android or Windows), medical Industry, Station, Parking, Logistic, Transportation, POST, Bank, insurance industry, industrial control systems, Scale, ect.
