Home - Products - Thermal Printer -

Printer 80mm

C80300I Receipt Printer
video
C80300I Receipt Printer

C80300I Receipt Printer

Model: C80300I
Description: Kitchen Printer, 80mm Printer
Key parameter: 80mm paper width (3inch)
83mm paper diameter
USB+Serial+Ethernet
250mm/s
Printer with auto cutter

Features:

C80300I is an 80mm thermal printer that is tailored for the bustling kitchen environment. It comes equipped with an extra-loud speaker and a flashing light pillar, ensuring that users are alerted if they forget to retrieve their receipts. Additionally, the printer is designed with a recessed area at the bottom, allowing for easy wall mounting and optimizing space in the kitchen.


1. C80300I Receipt printer with high speed printing

High-speed processor for fast speeds of up to 250mm/s, clear and stable printing.

2. C80300I Receipt printer, idea for Kitchen Printer

Built-in loudspeaker, big alarm for receipt notification and error indication.

Longer front light tube for obvious receipt printing and error indication.

3 Inch Thermal Printer supports detection and reminding function when receipt is not taken away.


Specification

Printing

Print method

Direct thermal line

Paper width

80mm

Paper diameter

Φ83mm (Max.)

Paper thickness

0.06~0.08mm

Dot Density

512 / 576dot/line

Print speed

250mm/s

Interface

USB+Serial+Ethernet

Line space

3.75mm (can be adjustive)

Commands

Compatible with ESC/POS

Character Size

ANK character, Font A:12x24dot

Font B:9x17dot

Simplified/Traditional Chinese:24x24dot

Code page

PC437, Katakana, PC850, PC860, PC863, PC865, West Europe, Greek, Hebrew, East Europe, Iran, WPC1252, PC866, PC852, PC858, IranII, Latvian, Arabic, PT151,1251, PC737, WPC, 1257, Thai Vietnam, PC864, PC1001, (Latvian), (PC1001), (PT151,1251), (WPC1257), (PC864), (Vietnam), (Thai)

Barcode mode

UPC-A, UPC-E, JAN13(EAN13), JAN8(EAN8)CODE39, ITF, CODABAR, CODE93, CODE128, QR code

Fonts

GB18030

Buffer

Data

32K bytes

NV Flash

60K bytes

Power

Cash drawer out

DC 24V/1A

Power adaptor

Input:AC 110V/220V, 50~60Hz Output:DC 24V/2A

Power supply

DC 24V/2A

Physical

Weight

1.40kg

Dimension

200x146x138mm

Environment

Work

Temperature: 5~45℃, Humidity: 10-80%

Storage

Temperature: -10~60℃ Humidity: 10~90%

Reliability

Mechanism

150km

Auto cutter

1.5 million cuts



Packing:

Product Model

Weight (kg)

Packing

C.G.W (kgs)

Carton Size (cm)

C80300I Receipt Printer

2.1

6 pcs/carton

13.5

68*50*29


Application:

C80300I receipt printer has various applications in foreign markets. Some of the key usage scenarios include:
1. Restaurants and Cafes: It can be used in busy kitchens to print receipts for food orders, helping to streamline the ordering and payment process.
2. Retail Stores: The printer can be utilized in retail environments to generate customer receipts for purchases, ensuring efficient transaction processing.
3. Hospitality Industry: Hotels, resorts, and inns can utilize the printer to provide guests with detailed invoices and receipts for their stay, enhancing customer service.
4. Transportation Services: It can be employed in taxi services, car rental companies, and other transportation businesses to issue receipts for fares and rental charges.
5. Healthcare Facilities: The printer can be used in hospitals, clinics, and pharmacies to generate receipts for medical services, prescriptions, and transactions.
6. Business Offices: It can find applications in offices for generating receipts for business expenses, reimbursements, and invoices.
7. Entertainment Venues: Places like cinemas, theaters, and amusement parks can utilize the printer to issue receipts for ticket sales and concessions.
8. Financial Services: Banks, insurance companies, and financial institutions can use the printer to provide customers with printed transaction records and receipts.
9. Events and Conferences: The printer can be utilized in event management to generate receipts for ticket sales, registrations, and merchandise purchases.
10. Public Services: Government agencies and organizations can employ the printer to issue receipts for various services, such as fees, permits, and licenses.
