80L POS Printer
Model: 80L
Description: thermal printer for pos, restaurant printer, thermal printer cheap, usb receipt printer, Ethernet receipt printer, 80mm receipt printer, printing receipt machine
Key parameter: 80mm paper width (3inch)
83mm paper diameter
USB, USB+Bluetooth, USB+WiFi
LAN, LAN+Bluetooth, LAN+WiFi
USB+Serial, USB+Serial+Bluetooth, USB+Serial+WiFi
USB+LAN, USB+LAN+Bluetooth, USB+LAN+WiFi
USB+Serial+LAN, USB+Serial+LAN+Bluetooth, USB+Serial+LAN+WiFi
160mm/s, or 200mm/s, or 260mm/s for option
150KM printer head life
1.5 million Cuts
Features:
Receipt printer, high speed printing, function stable and reliable
Printing speed: 160mm/sec, 200mm/s, 260mm/s for option
Wall mount available;
80L POS Printer supports IP modification across network segments
80L POS Printer supports reprinting function (USB+LAN, USB+Serial+LAN)
80L POS Printer supports queuing function (USB+LAN, USB+Serial+LAN)
80L POS Printer supports IAP update online;
With print-head over temperature protection function
80L POS Printer supports print prompt and error alarm;
Support QR code, PDF417;
Compatible with ESC/POS
With the function of avoiding missing orders
Specification
|
Printing |
Print method |
Direct thermal line |
||
|
Paper |
Width：79.5±0.5mm, Paper diameter：Φ80mm |
|||
|
Print width |
72mm |
|||
|
Dot Density |
512 or 576dot/line |
|||
|
Interface |
USB, LAN (Bluetooth, WiFi or option) |
USB+Serial, USB+LAN (Bluetooth, WiFi or option) |
USB+Serial+LAN (Bluetooth, WiFi or option) |
|
|
Print speed |
160mm/s |
200mm/s |
260mm/s |
|
|
Line space |
3.75mm (can be adjustive) |
|||
|
Column number |
Font A - 42 columns or 48 columns |
|||
|
Font B - 56 columns or 64 columns |
||||
|
Simplified/Traditional Chinese - 21 columns or 24 columns |
||||
|
Character Size |
ANK character, Font A：1.5*3.0mm (12×24dot) |
|||
|
Font B：1.1*2.1mm (9×17dot) |
||||
|
Simplified/Traditional Chinese：3.0*3.0 (24×24dot) |
||||
|
Paper way out |
Top paper out |
|||
|
Auto Cutter |
Partial |
|||
|
Character |
Code page |
PC437, Katakana, PC850, PC860, PC863, PC865, West Europe, Greek, Hebrew, East Europe, Iran, WPC1252, PC866, PC852, PC858, IranII, Latvian, Arabic, PT151,1251 |
||
|
1D Barcode |
UPC-A, UPC-E, JAN13(EAN13), JAN8(EAN8), CODE39, ITF, CODABAR, CODE93, CODE128 |
|||
|
2D Barcode |
QRCODE, PDF417 ( except USB+Serial/USB/LAN) |
|||
|
Buffer |
Input buffer |
64K bytes |
USB+Serial: 64K bytes USB+LAN: 128K bytes |
128K bytes |
|
NV Flash |
256K bytes |
|||
|
Power |
Power adaptor |
Input：AC 110V/240V, 50~60Hz |
||
|
Power Input |
DC 24V/2.5A |
|||
|
Cash drawer |
DC 24V/1A |
|||
|
Physical properties |
Weight |
1.0kg |
||
|
Dimension |
190.13*140*134.64mm |
|||
|
Environment |
Work environment |
Temperature: 0~45℃, Humidity:10-80% |
||
|
Storage environment |
Temperature: -10~60℃ Humidity:10~90% |
|||
|
Reliability |
Mechanism |
150km |
||
|
Auto cutter |
1.5 million cuts |
|||
|
Software |
Emulation |
ESC/POS |
||
|
Driver |
Windows, JPOS, Linux, OPOS, Android, Mac |
|||
|
Utility |
Windows & Linux test utility |
|||
|
SDK |
iOS, Android, Windows |
|||
Packing:
|
Product Model |
Weight (kg) |
Packing |
C.G.W (kgs) |
Carton Size (cm) |
| 80L POS Printer |
1.5 |
12 pcs/carton |
23 |
59*53*39 |
Application:
The 80mm receipt printer 80L POS Printer has found wide application in various settings where there is a need for printing receipts. At the point of sale or in retail shops, the machine can be used to print receipts for purchases made by customers. In restaurants and cafes, it can be used to print bills and receipts for the customers.
In banking halls, it is used to print out transaction receipts and account statements. The 80mm receipt printer is also useful in public transportation like airports, train stations, and bus terminals where it can be used to print boarding passes and travel receipts.
In healthcare settings, the machine is used to print patient receipts, medical test results, and reports. It is also used in car rental companies where it is used to print rental agreements and receipts.
In addition, the 80mm receipt printer can be used in various administrative settings where there is a need for document tracking and control. It is useful in printing invoices, office memos, and official reports.
Overall, the 80mm receipt printer makes receipt printing quick and easy, making it an essential component in several industries such as retail, hospitality, transportation, and healthcare.
