CPU

32bits

Scan Type

bidirectional

Light source

360nm-830nm WHITE LED, 635nm RED LED

Reading mode

Manual and continuous (standard)，automatic (optional)

Buzzer

LED, Beeper

Print Contrast

≥ 20%

Resolution

≥4mil

Decode Speed

300 times/second

Bit Error Rate

1/5 million, 1/20 million

Scan Width

5mm~300mm

Depth of field

Code 39: 28mm-155mm (5mil)

PDF 417: 28mm-95mm (6.67mil)

Data Matrix: 25mm-95mm (10mil)

EAN-13: 40mm-355mm (13mil)

QR: 25mm-150mm (15mil)

Scan Angle

Roll: 360°, tilt: ± 60°, tilt: ± 60°.

Anti-interference

Industrial lighting or the sun won't make a difference

Decoding Capability

1D: Code 128, EAN-8, EAN-13, UPC-E, UPC-A, Code 39, Code 32, Trioptic 39, Codabar, Code 93, ITF 25, Matrix 25, Industrial 25, Airline 25, Plessey, MSI, Code 11, GS1-Databar，Compsite, Aztec Code，AU Postal Code，Codablock A&F，ENG Postal Code，JP Postal Code，KIX Postal Code，Pharma Code，PLANET Code，POSTNET Code，Royal Infomail Code，Telepen，Trioptic Code，UPU Postal Code

2D: QR Code, PDF417, DataMatrix, Chinese Sensible Code, HANXIN Code

Electrical parameter

5 VDC±5%, Operating 240mA, Standby 100mA

Button Life

8000000 times, laser lifespan: 12:000 hours

Fall test

1.8M

Interface

USB(HID AND VCOM), RS232, PS/2
