M60W Windows POS
Model: M60W
Description: all in one touch pos, all in one touch screen pos, monitor pos
Key parameter: 15.6 inch single display
1920*1080 resolution
Touch screen
Windows OS
Built-in 80mm thermal printer with auto cutter
220mm/s printing speed
Features:
M60W Windows POS equipped with an octal-core CPU in high configuration and can realize multiple displays with double screens.
In addition the product is compatible with various auxiliary cash register such as the external barcode scanner, cash drawer and etc... Which can effectively enhance cash registering efficiency for users.
1. Windows OS
2. J1900, 2.0GHz
3. 4G+128G
4. 15.6" main display, touch screen
5. 11.6" guest display for optional
6. Built-in 80mm thermal printer with 220mm high print speed
Specification
|
Control Component |
|
|
Operation System |
Windows 7 (standard) Windows 10 (optional) |
|
CPU |
J1900 2.0GHz |
|
Memory |
4GB |
| Storage | 128GB SSD |
|
Speaker |
Realtek ALC662 HD Audio decoding controller |
|
Main Display |
|
|
Display Screen |
15.6 inch |
|
Resolution |
1920*1080 Pixel (Standard) |
|
Operation |
10 points touch capacitive screen |
|
Guest Display (optional) |
|
|
Display Screen |
11.6 inch |
|
Resolution |
1380*768 Pixel |
|
I/O Port |
|
|
USB |
3* USB2.0, 1*USB3.0 |
|
LAN |
1* RJ45 (10/100M) |
|
Video |
1* VGA, 1* HDMI |
|
Audio |
1* LINE-OUT, 1* MIC-IN |
|
Physical properties |
|
|
Power |
12V |
|
Color |
Black, White |
|
Dimension |
400x270x420mm (LxWxH) |
Built-in thermal printer specification:
|
Built-in Printer |
|
|
Paper width |
80mm |
|
Paper diameter |
80mm |
|
Cutter |
Partial cut |
|
Print speed |
220mm/sec |
|
Resolution |
203 DPI |
|
Commands |
Compatible with ESC/POS |
|
Fonts |
GB18030, BIG5, KSC5601, SHIFT JIS |
|
Character Size |
ANK character, Font A：12x24dot |
|
Font B：9x17dot |
|
|
Simplified/Traditional Chinese：24x24dot |
|
|
Code page |
PC437, Katakana, PC850, PC860, PC863, PC865, West Europe, Greek, Hebrew, East Europe, Iran, WPC1252, PC866, PC852, PC858, IranII, Latvian, Arabic, PT151,1251, PC737, WPC, 1257, Thai Vietnam, PC864, PC1001, (Latvian), (PC1001), (PT151,1251), (WPC1257), (PC864), (Vietnam), (Thai) |
|
Reliability |
Mechanism: 150KM; Auto cutter: 1.5 million cuts |
Packing:
|
Product Model |
Weight (kg) |
Packing |
C.G.W (kgs) |
Carton Size (cm) |
| M60W Windows POS |
6 |
1 pcs/carton |
8.8 |
39*48*50 |
